Structure: The pin arrangement corresponds to the pin arrangement and consists of a row of holes with metal shrapnel inside, which are usually embedded in the plastic base.
Matching: the hole position and spacing of the row mother are designed to match the stitches of the row needle. When in use, the pins of the pin arrangement are inserted into the holes of the pin arrangement, and the metal shrapnel provides necessary electrical contact and mechanical fixation.
method of application
Design matching: ensure that the number and spacing of stitches match the arrangement of row mother.
Welding pin arrangement: align the pins of pin arrangement correctly and weld them vertically to the circuit board.
Connecting the bus bar: align the bus bar with the pin bar and press it gently so that the pin bar is completely inserted into the bus bar. In order to prevent the damage of stitches or plugs, excessive force should be avoided.
Check the connection: make sure that the pin arrangement and the pin arrangement are firmly connected and all pins are correctly connected.
